RCI F1114/F1119 Centerline

The dormakaba RCI F1114 and RCI F1119 are centerline electric strikes: fail-secure strikes made of stainless steel with a square-cornered faceplate. The RCI F1114 suits hollow metal frames and the RCI F1119 is best used with aluminum and wood frames.

Fit and adjustment: the F1 series accommodates 1/2 in. (12.7 mm), 5/8 in. (16 mm) or 3/4 in. (19 mm) latch projection and allows up to 1/4 in. (6.4 mm) horizontal adjustment to relieve side-load pressure and ensure proper latch alignment. The strikes are saddle-mounted for strength, have a built-in anti-vibration feature and a concealed Pry-Guard for tamper resistance. Mounting tabs, shims and fasteners are included, and the strikes are non-handed.

Strength, listings and power: 1,500 lbf (6,672 N) static and 70 ft-lb (95 J) dynamic strength, 500,000 cycles, certified to ANSI/BHMA A156.31, Grade 1. The strikes are UL 1034 (Underwriters Laboratories) burglary-resistant listed and fire-rated 1-1/2 hours to UL 10C and CAN/ULC S104. The energy-efficient coil draws 200 mA at 12 VDC and accepts 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC. Fail-secure means the strike stays locked when power is removed. 5 year limited warranty.

  • 1,500 lbf (6,672 N) static and 70 ft-lb (95 J) dynamic strength; 500,000 cycles
  • Accommodates 1/2 in., 5/8 in. or 3/4 in. (12.7, 16 or 19 mm) latch projection
  • Up to 1/4 in. (6.4 mm) horizontal adjustment for latch alignment
  • Fire-rated 1-1/2 hours: UL 10C and CAN/ULC S104; UL 1034 burglary-resistant; ANSI/BHMA A156.31 Grade 1
  • Fail-secure; non-handed
  • 200 mA at 12 VDC; 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC
  • 5 year limited warranty

Product Details

  • Accommodates 1/2 in. (12.7 mm), 5/8 in. (16 mm) or 3/4 in. (19 mm) latch projection
  • Up to 1/4 in. (6.4 mm) horizontal adjustment relieves side-load pressure and ensures proper latch alignment
  • Saddle-mount housing design for strength and durability
  • Tamper-resistant Pry-Guard concealed inside the frame
  • Built-in anti-vibration feature
  • Energy-efficient coil design
  • Mounting tabs, shims and fasteners included
  • Non-handed
  • 200 mA, 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC (max at 12 VDC)
  • 1,500 lbf (6,672 N) static, 70 ft-lb (95 J) dynamic
  • 500,000 cycles
  • Fail-secure
  • CAN/ULC S104 and UL 10C, 1-1/2 hours
  • 5 year limited warranty

Technical Details

F1114 Centerline Strike

  • Faceplate: 1-1/4 in. W x 4-7/8 in. H (32 mm x 124 mm)
  • Insert depth: 1-3/4 in. (45 mm)

F1119 Centerline Strike

  • Faceplate: 1-3/8 in. W x 9 in. H (34 mm x 229 mm)
  • Insert depth: 1-3/4 in. (45 mm)

Shared Technical Information

  • Latch projection: 1/2 in., 5/8 in. or 3/4 in. (12.7, 16 or 19 mm)
  • Strength: 1,500 lbf (6,672 N) static, 70 ft-lb (95 J) dynamic
  • Voltage: 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC; 200 mA at 12 VDC
  • Mode: fail-secure
  • Finish: Brushed Stainless Steel (32D)
  • UL 1034 burglary-resistant listed
  • UL 10C, 1-1/2 hour fire rating listed
  • CAN/ULC S104, 1-1/2 hour fire rating listed
  • Certified to ANSI/BHMA A156.31, Grade 1; endurance 500,000 cycles

Components

Accessories

  • ICEPK: heat reducer for continuous duty electric strikes

Applications

  • Commercial Centers
  • Industrial Buildings
  • Educational Facilities
  • Retail Outlets
  • Health Care Facilities
  • Office Complexes
F1114 Centerline Electric Strikes RCI EAD
F1119 Centerline Electric Strikes RCI EAD
