RCI 12C Compact

Name: RCI 12C Compact
Brand: dormakaba
SKU: KA_500265

The dormakaba RCI 12C is a compact electric strike, a versatile solution suitable for all types of door frames. It replaces a standard, non-electrified T-strike with a quick and easy to install electric version while maintaining the integrity and strength of the door frame.

The compact body measures 1-13/16 in. W x 2-3/4 in. H x 1-1/8 in. D (46 mm x 70 mm x 28 mm) and is suited to wooden, steel and aluminum door frames. The strike is non-handed and finished in Brushed Chrome (26D).

Strength and power: 1,100 lbf (4,893 N) static and 44 ft-lb (60 J) dynamic (internal testing). The strike is fail-secure, meaning it stays locked when power is removed, and draws 90 mA at 12 VDC. It carries a 1 year limited warranty. An ICEPK heat reducer is available for continuous duty.

Replaces standard, non-electrified T-strikes: quick and easy to install
Compact: 1-13/16 in. W x 2-3/4 in. H x 1-1/8 in. D (46 mm x 70 mm x 28 mm)
Suited to wooden, steel and aluminum frames; non-handed
1,100 lbf (4,893 N) static and 44 ft-lb (60 J) dynamic (internal testing)
Fail-secure; 90 mA at 12 VDC
1 year limited warranty

Product Details

Quick and easy to install
Suited to wooden, steel and aluminum frames
Non-handed
Versatile, compact design
90 mA, 12 VDC
1,100 lbf (4,893 N) static, 44 ft-lb (60 J) dynamic (internal testing)
Fail-secure
1 year limited warranty

Technical Details

Dimensions: 1-13/16 in. W x 2-3/4 in. H x 1-1/8 in. D (46 mm x 70 mm x 28 mm)
Strength: 1,100 lbf (4,893 N) static, 44 ft-lb (60 J) dynamic (internal testing)
Voltage: 12 VDC; 90 mA
Mode: fail-secure
Replaces standard, non-electrified T-strikes
Maintains the integrity and strength of the door frame
Finish: Brushed Chrome (26D)
