RCI VR165 Vertical Rod

The dormakaba RCI VR165 is a vertical rod electric strike designed for use with vertical rod exit devices that have a roller latch. This heavy-duty, surface-mounted strike accommodates a 5/8 in. (16 mm) roller latch and is made of high-grade stainless steel for keeper strength.

Design: the conventional keeper (one moving part) promotes even load distribution. A horizontal solenoid prevents manipulation by vibration. Up to 1/4 in. (6.4 mm) adjustment compensates for door and frame misalignment, and a door stop adjustment suits different rail thicknesses. Lockdown tabs with HEX socket head cap screws give a secure, tamper-resistant mount; a HEX key is included. The strike is non-handed and uses a plug-in wire connector.

Strength, power and listings: 1,500 lbf (6,672 N) static and 70 ft-lb (95 J) dynamic, 250,000 cycles, fail-secure (stays locked when power is removed). The strike draws 450 mA at 12 VDC on field-selectable 12/24 VDC or 12 to 24 VAC. It is UL 1034 (Underwriters Laboratories) burglary-resistant listed and UL 294 (6th edition) listed as an access control unit accessory, with a 5 year limited warranty.

  • For vertical rod exit devices with a 5/8 in. (16 mm) roller latch
  • 1,500 lbf (6,672 N) static and 70 ft-lb (95 J) dynamic strength; 250,000 cycles
  • Heavy-duty surface-mounted stainless steel strike with one-piece keeper
  • Up to 1/4 in. (6.4 mm) adjustment for door and frame misalignment; door stop adjustment for rail thickness
  • Fail-secure; non-handed; horizontal solenoid resists vibration
  • 450 mA at 12 VDC; field-selectable 12/24 VDC or 12 to 24 VAC
  • UL 1034 and UL 294 listed; 5 year limited warranty

Product Details

  • Accommodates 5/8 in. (16 mm) roller latch
  • Heavy-duty, surface-mounted strike
  • High-grade stainless steel for keeper strength
  • Up to 1/4 in. (6.4 mm) adjustment to compensate for door and frame misalignment and ensure proper latch alignment
  • Door stop adjustment for different rail thicknesses
  • Horizontal solenoid prevents manipulation from vibration
  • Conventional keeper design (one moving part) promotes even load distribution
  • Lockdown tabs for a secure mount
  • Non-handed
  • HEX socket head cap screws for added support and tamper resistance
  • Plug-in wire connector
  • Installation tool included (HEX key)
  • 450 mA, field-selectable 12/24 VDC or 12 to 24 VAC (max at 12 VDC)
  • 1,500 lbf (6,672 N) static, 70 ft-lb (95 J) dynamic
  • 250,000 cycles
  • Fail-secure
  • 5 year limited warranty

Technical Details

  • Roller latch: 5/8 in. (16 mm)
  • Strength: 1,500 lbf (6,672 N) static, 70 ft-lb (95 J) dynamic
  • Endurance: 250,000 cycles
  • Voltage: field-selectable 12/24 VDC or 12 to 24 VAC; 450 mA at 12 VDC
  • Mode: fail-secure
  • Finish: Brushed Stainless Steel (32D)
  • UL 1034 burglary-resistant listed
  • UL 294 listed for Access Control Unit Accessory (6th edition)
  • Patents: US 7,722,097; Canada 2,597,916

Applications

  • Commercial Centers
  • Industrial Buildings
  • Educational Facilities
  • Retail Outlets
  • Health Care Facilities
  • Office Complexes
