RCI 4 Series Centerline

Name: RCI 4 Series Centerline
Brand: dormakaba
SKU: KA_500261

The dormakaba RCI 4 Series is a centerline electric strike for 3/4 in. (19 mm) latch projection. Its various faceplate options and 1-1/2 in. (38 mm) cut-out depth accommodate most door frame types and materials, and it works with door thicknesses from 1-3/8 to 2-3/8 in. (35 to 60 mm). The 41 Series is fail-secure and the 43 Series is fail-safe: a fail-secure strike stays locked when power is removed, a fail-safe strike unlocks.

Installation: standard mounting tabs and fasteners are included, and a trim plate covers an irregular frame cut-out. Crossed wires are never a problem because the coil is not polarity sensitive. The strike is non-handed and draws 200 mA at 12 VDC on 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC.

Strength by faceplate: 1,500 lbf (6,672 N) static for fire-rated models, 1,000 lbf (4,448 N) for non-fire-rated 04 and 14 faceplates, and 500 lbf (2,224 N) for 05, 07, 08 and 19 faceplates; 70 ft-lb (95 J) dynamic. Endurance is 500,000 cycles for fire-rated (F) models and 250,000 cycles for other models.

Listings: UL 1034 (Underwriters Laboratories) burglary-resistant listed. Optional 1-1/2 hour fire-rated models are listed to UL 10C and CAN/ULC S104 and certified to ANSI/BHMA A156.31, Grade 1; fire-rated (F) models are available only in fail-secure mode with 04 and 14 faceplates. 5 year limited warranty.

4 Series 4104 4304 Electric Strikes RCI EAD

Accommodates 3/4 in. (19 mm) latch projection; 1-1/2 in. (38 mm) cut-out depth fits most frame types
Fail-secure (41 Series) or fail-safe (43 Series)
1,500 lbf (6,672 N) static for fire-rated models, 1,000 lbf (4,448 N) for non-fire-rated 04 and 14 faceplates, 500 lbf (2,224 N) for 05, 07, 08 and 19 faceplates; 70 ft-lb (95 J) dynamic
500,000 cycles (fire-rated F models), 250,000 cycles (other models)
Optional 1-1/2 hour fire-rated models (fail-secure, 04 and 14 faceplates only)
200 mA at 12 VDC; 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC; coil not polarity sensitive
UL 1034 burglary-resistant listed; 5 year limited warranty

Product Details

Accommodates 3/4 in. (19 mm) latch projection
1-1/2 in. (38 mm) cut-out depth accommodates most door frame material types
Use with a wide range of door thicknesses, 1-3/8 to 2-3/8 in. (35 to 60 mm)
Standard mounting tabs and fasteners included
Non-handed
Trim plate included to cover an irregular frame cut-out
Coil is not polarity sensitive
200 mA, 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC (at 12 VDC)
1,500 lbf (6,672 N) static (1,500 lbf (6,672 N) for fire-rated models, 1,000 lbf (4,448 N) for non-fire-rated 04 and 14 faceplates, 500 lbf (2,224 N) for 05, 07, 08 and 19 faceplates), 70 ft-lb (95 J) dynamic
500,000 cycles (fire-rated (F) models only; 250,000 for other models)
Fail-secure (41 Series) and fail-safe (43 Series)
Optional 1-1/2 hour fire-rated models available (fire-rated (F) models only available in fail-secure mode with 04 and 14 faceplates)

Technical Details

Insert depth: 1-1/2 in. (38 mm)
Latch projection: 3/4 in. (19 mm)
Door thickness: 1-3/8 to 2-3/8 in. (35 to 60 mm)
Strength: 1,500 lbf (6,672 N) static (fire-rated models), 1,000 lbf (4,448 N) (non-fire-rated 04 and 14 faceplates), 500 lbf (2,224 N) (05, 07, 08 and 19 faceplates); 70 ft-lb (95 J) dynamic
Endurance: 500,000 cycles (fire-rated (F) models), 250,000 cycles (other models)
Voltage: 11 to 16 VAC, 12 VAC/VDC or 24 VAC/VDC; 200 mA at 12 VDC
Mode: fail-secure (41 Series) or fail-safe (43 Series)
Finish: Brushed Stainless Steel (32D)
UL 1034 burglary-resistant listed
UL 10C, 1-1/2 hour fire rating listed (fire-rated (F) models only, available in fail-secure mode with 04 and 14 faceplates)
CAN/ULC S104, 1-1/2 hour fire rating listed (fire-rated (F) models only, available in fail-secure mode with 04 and 14 faceplates)
Certified to ANSI/BHMA A156.31, Grade 1; endurance 500,000 cycles (fire-rated (F) models only, 250,000 for other models)

Components

Accessories

4/7JIG: standard profile frame prep jig, aluminum
LEK01: 1 in. (25 mm) lip extension kit for retrofit applications, black finish (not available for F4 fire-rated series)
LEK02: 2 in. (51 mm) lip extension kit for retrofit applications, black finish (not available for F4 fire-rated series)
LEK03: 3 in. (76 mm) lip extension kit for retrofit applications, black finish (not available for F4 fire-rated series)
SMT-01: strike marking template kit, aluminum
TP-47-5PK: trim plates, 5 pack, black finish
930-LG: standard profile latch guard, 32D finish
