Product Summary

The DB25K incorporates the same advanced design, quality and electronic ingenuity as the DB25 with the added flexibility of a manual key override.

Despite the addition of the key override mechanism, the streamlined design is maintained allowing the DB25K to provide a high security, yet versatile, door locking solution.

  • Holding force: 10,000N (1,000kg)
  • Security for commercial and residential single-, double acting doors & glass doors
  • Manual key override
  • Automatic deadbolting providing high security
  • Versatile Installation possible

Product Details

  • Euro style key cylinder can be used to manually control the lock
  • Automatic deadbolting
  • 12.7mm diameter stainless steel bolt pin
  • Anti-tailgate and Anti-tamper
  • Auto-relock after 0/3/6/9 seconds
  • Multiple attempts to lock and unlock
  • Thermal overheating protection
  • Reverse polarity and transient protection
  • Dual monitoring with door and bolt position monitors
  • Mortice mount horizontally or vertically, on single or double acting doors
  • Surface mount with the aid of the DB25K accessories, including mounting onto glass

Technical Details

  • Holding force: 10,000N (1,000kg
  • Voltage at lock: 12-24VDC +/- 10%
  • Endurance: 1,000,000 cycles normal operation
  • Materials: Plastics (POM), Stainless Steel (304)


  • Lock: 280L x 25W x 42D (mm)
  • Short strike: 140L x 25W x 3D (mm)
  • Long strike: 280L x 25W x 3D (mm)
  • Bolt housing: 294L x 29W x 46.5D (mm)
  • Strike housing: 294L x 29W x 46.5D (mm)
  • Dress plate: 294L x 0.7W x 50D (mm)

DB25K - Electronic Deadbolt Lock
