RCI 9320 & RCI 9321 Easy Read Prox Slimline Readers

The dormakaba RCI 9320 and RCI 9321 Easy Read Prox Slimline Readers are single-door standalone proximity reader solutions for surface or mullion mount applications, indoors or outdoors. The RCI 9320 is a self-contained unit, whereas the RCI 9321 is two separate components, a reader and a controller.

Programming and capacity: both are easy to install, need no separate programmer and support up to 10,000 users for large-scale standalone access control. Access validation can be silent (9320 only), audible or visual, and a user can be denied access without retrieving their card or fob.

Power and mode: 1,000 mA at 12 VDC maximum, field-selectable fail-safe or fail-secure, with an input trigger for request to exit (REX) or another open-circuit contact. Read range is up to 2-3/8 in. (60 mm) with the 932-10CP card and 1-9/16 in. (40 mm) with the 932-10KP fob.

  • Supports up to 10,000 users
  • Read range: up to 2-3/8 in. (60 mm) using the 932-10CP card, 1-9/16 in. (40 mm) using the 932-10KP fob
  • Field-selectable fail-safe or fail-secure
  • Rugged, weather-resistant design for interior or exterior use
  • Power: 1,000 mA at 12 VDC (max)
  • 1 Year Limited Warranty

Product Details

  • Easy to install
  • Supports up to 10,000 users
  • Slim surface or mullion mount design
  • Access validation: silent (9320 only), audible or visual
  • Deny access without retrieving the user's card or fob
  • No separate programmer required
  • Input trigger for request to exit or other open-circuit contac
  • Includes black and white snap-on covers
  • Proximity cards and fobs are available in packs of 10 (sold separately)

Technical Details

Dimensions: 1-1/2 in. W x 3-1/16 in. H x 1/2 in. D (38 mm x 78 mm x 12.7 mm)

9320 Reader, Stand Alone

  • One self-contained unit

9321 Reader + Controller

  • Two separate components

Components

Accessories

  • 932-10CP: encoded card starter pack, 10 pack, includes wallet and programming cards
  • 932-10KP: encoded fob starter pack, 10 pack, includes wallet and programming cards
9321_Switches RCI EAD
