SAM RF Software

Name: SAM RF Software
Brand: dormakaba
SKU: KA_235359

SAM RF™ software is a legacy dormakaba Windows-based program that offers point-and-click functionality for fast key making, database management, report creation and work order processing. A few keystrokes complete the key programming process, and SAM RF can interface with existing property management systems.

Single or multiple properties: SAM RF can control multiple properties from a single database, which centralizes key control and key making. Multiple SAM RF databases can be added to a single server and networked across your communities, allowing site-level key control as well as overall administrative control from a central location.

Reports: SAM RF users can request building management reports, including an extensive transaction history, unit key history, key-user history, keys made, limited-use audits and lock audits.

Product Details

SAM RF software is intuitive from installation, and dormakaba can work with your management to set up the database to the property's design.

Drop-down menus for programming keys, setting up users and authorizations, and generating system transaction reports
Customizable authorization groups give management control over employee access and key-making restrictions
ID and password protection for added security and administration
Multiple database option to manage several properties from a single system
Multiple, customizable key levels: Resident, Zone, Master, Limited Use and Emergency

Audit Trail

InSync locks keep entry records by time, date and key ID. Non-volatile memory maintains programming and audit information.

Dual Technology: Single-Key Convenience

An InSync RFID key with dual technologies combines the standard HiTag with Prox, MIFARE® or DESFire® technology. One credential can then work with many RFID access readers, avoiding the cost of new access readers. This suits properties where a common credential must work alongside hard-wired access control systems.

InSync Configuration

Unit function: designed for apartment entry, offices, utility rooms and more
Suite function: for multiple leases per apartment, such as student housing. If one resident loses a key, the new key cancels the lost key and roommates keep access.
Common function: for perimeter entries and amenity spaces. Common locks can be restricted by time schedule and use, which suits pay-for-use amenity areas.

Components

The SAM RF system includes the following components:

SAM RF System Software CD (program software and USB drivers)
Electronic Key Encoder Base
SAM RF System Utility Device
Electronic keys: preprogrammed (construction) and un-encoded (key)
Power source for the Electronic Key Encoder
USB cable for the Electronic Key Encoder
USB cable for the Utility Device
External Power Supply (EPS)

RF Key

An encrypted code is programmed into the RFID key, making it a unique credential. The credential tells the lock to allow or deny access. Each exchange of information between lock and RFID key is stored in the lock and available for audit.

Rugged Durability

The RFID key communicates with the lock by radio frequency (RF) when inserted into the lock's key port. It needs no physical electrical contact points: it receives power and communications through proximity, so unlike metallic contacts it does not need protection from corrosion or from wear caused by repeated use. The key is made of a special polymer that is impervious to moisture and can be inserted into the key port in any direction.

Single-Key Convenience

One RFID key can operate private residence locks as well as multiple common area locks chosen by management, which suits residential communities with a variety of amenities.

Expiration and Cancellation

RFID keys work continuously, expire at a programmed time, or stop working when canceled by the operating system. An expiration date is programmed on each key when it is made. An RFID key can be reprogrammed as many times as needed and automatically cancels the previous RFID key (for example, if it is lost or stolen) without reprogramming the lock.
