RCI 970 Illuminated Exit

The dormakaba RCI 970 Illuminated Exit is a push to exit illuminated push button available with blue (standard), yellow, green or red lens options. The beveled-edge RCI 970 request-to-exit button is designed to discourage tampering: a special driver and tamper-proof screws are included to prevent unauthorized faceplate removal.

Momentary (2-SPST or 4-SPST), maintained (2-SPST or 4-SPST) or time-delay (DPDT) switches are available, where SPST is single pole single throw and DPDT is double pole double throw, giving flexibility in operation. 12 and 24 VAC/VDC options are available.

The RCI 970 mounts quickly to a single gang box (Standard) or to narrow-stile door frames (Narrow). Its extruded aluminum 1/4 in. (6 mm) plate has beveled edges for tamper-resistance and durability, and the faceplate comes in Brushed Anodized Aluminum (28) or Brushed Anodized Dark Bronze (40).

  • Illuminated push button with blue (standard), yellow, green or red lens options
  • Momentary (2-SPST or 4-SPST), maintained (2-SPST or 4-SPST) or time-delay (DPDT) switch options
  • Tamper-resistant: extruded aluminum 1/4 in. (6 mm) plate, special driver and tamper-proof screws included
  • Standard (single gang box) or narrow-stile mounting; 12 and 24 VAC/VDC options
  • 3 year limited warranty

Product Details

  • Illuminated pushbutton
  • Quickly mounts to single gang box (Standard) or narrow-stile door frames (Narrow)
  • Extruded aluminum 1/4 in. (6 mm) plate with beveled edges for tamper-resistance and durability
  • Hardware kit includes stainless steel tamper-proof screws and spanner bit
  • Momentary (2-SPST or 4-SPST), maintained (2-SPST or 4-SPST) or time-delay (DPDT) switches available
  • 12 and 24 VAC/VDC options available
  • Blue (standard), yellow, green or red lens options
  • Faceplate available in Brushed Anodized Aluminum (28) or Brushed Anodized Dark Bronze (40) finish

Technical Details

  • Standard: 3 in. W x 4-3/4 in. H (76 mm x 121 mm)
  • Narrow: 1-5/8 in. W x 4-3/4 in. H (41 mm x 121 mm)
  • Warranty: 3 year limited warranty

Components

Accessories

  • 9SURBOX: surface-mount single gang box
  • TD30 : 30 second fixed timer (12/24 VDC)
  • TD30A: 0 to 30 second adjustable timer (12/24 VDC)

Applications

  • Commercial and industrial
  • Vandal-prone areas
  • Vestibules
  • Storefront
  • Health care
