RCI 940 Rectangular Push Plate

The dormakaba RCI 940 Rectangular Push Plate is a rectangular push plate with a large 2-3/4 in. W x 4-1/2 in. H (70 mm x 114 mm) stainless steel faceplate. Its beveled edges make it a dependable, tamper and vandal resistant push plate for automatic door activation.

The faceplate is connected as a universal touch area, so pressure on any part of the plate activates the switch. Text and symbols are baked onto the surface for durability.

The RCI 940 uses momentary single pole double throw (SPDT) switch operation, with a double pole double throw (DPDT) accessory kit available. It comes in Brushed Stainless Steel (32D) finish and carries a lifetime limited warranty.

  • Large 2-3/4 in. x 4-1/2 in. (70 mm x 114 mm) rectangular stainless steel faceplate
  • Universal touch area: push at any location on the plate
  • Beveled edges provide a tamper and vandal resistant solution
  • Momentary (SPDT) switch operation, DPDT accessory kit available
  • Brushed Stainless Steel (32D) finish; lifetime limited warranty

Product Details

  • Large rectangular faceplate
  • Beveled edges provide a tamper and vandal resistant solution
  • Universal touch area; push at any location
  • Momentary (SPDT) switch operation, DPDT accessory kit available
  • Text and symbols are baked onto the surface for durability
  • Brushed Stainless Steel (32D) finish
  • Lifetime limited warranty

Technical Details

  • Dimensions: 2-3/4 in. W x 4-1/2 in. H (70 mm x 114 mm)
  • Warranty: lifetime limited warranty

Components

Accessories

  • 9SURBOX: surface-mount single gang box
  • TD30: 30 second fixed timer (12/24 VDC)
  • TD30A: 0 to 30 second adjustable timer (12/24 VDC)
  • P94/5DMO: DPDT momentary contact switch kit

Applications

  • Handicap areas
  • Vandal-prone areas
  • Vestibules
  • Storefront
  • Commercial
  • Industrial
  • Health care
