RCI 909 Rocker Switch

Name: RCI 909 Rocker Switch
Brand: dormakaba
SKU: KA_500285

The dormakaba RCI 909 Rocker Switch is a rocker switch for door control from a desk or wall mount location. With the RCI 909F surface-mount version, the switch can be concealed under a desk or counter.

The switch has a smooth rocker action and is engraved with a key symbol. It is available in momentary (SPDT) and maintained (SPDT) versions, where SPDT is single pole double throw, and its contacts are rated 10 A at 250 VAC.

The RCI 909 comes in a beige finish and carries a 2 year limited warranty.

Desk or wall mount door control; 909F surface-mounts under a desk or counter for concealment
Smooth action rocker with key symbol
Momentary (SPDT) or maintained (SPDT) switch options
Contacts rated 10 A at 250 VAC
Beige finish; 2 year limited warranty

Product Details

Suited to desk or wall mount applications
Surface-mounts under desk or counter for concealment
Smooth action rocker with key symbol
Momentary (SPDT) and maintained (SPDT) switches available
10 A at 250 VAC
Beige finish
2 year limited warranty

Technical Details

Surface-mount (909F): 2-7/16 in. W x 2-7/16 in. H x 7/8 in. D (61 mm x 61 mm x 22 mm)
Flush-mount: 3-7/16 in. W x 3-7/16 in. H x 5/8 in. D (87 mm x 87 mm x 16 mm)
Contact rating: 10 A at 250 VAC
Warranty: 2 year limited warranty
