SVP / M-SVP-S Controls

The SVP and M-SVP control units enable the use of dormakaba motor locks with a full range of functions. Depending on the model and in addition to the conventional activation functions of short-term and permanent door releases via access control systems or intercoms, it is possible to trigger further functions, such as the latch locking during day function, automatic drives for actuation impulses, signals for alarm systems, electrical disconnections of access control / entry for GMA, etc. It is also possible to analyse various types of feedback regarding the condition of the lock.

For the activation of dormakaba motor locks
Feedback about lock condition
Connection of automatic drives
Version-dependent special functions
Special functions, e.g. timer, networking, etc.
Versions with or without power supply unit

Product Details

SVP-S 3x DCW®
For operating SVP or M-SVP self-locking panic motor locks in stand-alone mode with full functionality This control unit offers various inputs and outputs, no configuration via software required. Configured for motorized locking and unlocking of the door via access control systems (on-site); control unit and lock are connected via the DCW® system bus.

SVP-S 4x DCW® (Article in discontiuation)
Control unit for operating SVP 2000 DCW® or M-SVP 2200 DCW® self-locking panic motor locks in stand-alone mode. Control unit and lock are connected via the DCW® system bus.
With freely programmable inputs and outputs for switching unlocking functions or outputting feedback signals as well as an integrated timer and LON/LAN networking option. Available in various equipment variants.

SVP-S 5x
The SVP-S 5x control unit is designed for the operation of SVP or M-SVP locks (single-leaf) or SVA and SVI locks (double-leaf). It enables the door to be locked and unlocked via access control systems (on site). The control unit can be connected to the lock via a tamper-proof 4-wire DCW® system bus; LAN or LON networking is possible if required. The factory pre-parameterized inputs and outputs automatically adapt to the respective lock type. It has plug-in, removable screw terminals with measuring contacts and separate status LEDs for simple status monitoring. Control integration into fire alarm systems (FAS) is also possible. Advanced parameterization is carried out via the RS232 interface with the TMS software from version 5.0.050.

M-SVP 2000 control unit
Optional external surface-mounted control unit with power supply unit for M-SVP 2000 multi-point locks. This can be used instead of the internal control unit supplied with the locks. The inputs and outputs are used to switch unlocking functions (incl. day latch function) and output feedback signals.

M-SVP 3000 control unit
Surface-mounted control unit with power supply unit for controlling M-SVP 3000 and M-SVP 3500 multi-point locks. The inputs and outputs are used to switch unlocking functions and output feedback signals.
