Product Summary

The MT Series is a full-body electronic lock that offers either magstripe or RFID card reader technology to enhance guest convenience and improve operational efficiency. Ideal for retrofits, this lock works with the Windows-based System 6000™, Messenger LENS™ online wireless system and DeskLinc™ front desk system.

The MT RFID is able to operate using the dormakaba Mobile Key System and can be offered with the following options: Bluetooth Low Energy (BLE) compatible, ready or enabled.

Product Details

  • High security and tamperproof design
  • 1" solid deadbolt (optional auto deadbolt)
  • Mag stripe or RFID card reader options
  • Staff monitoring - Keycard audits (RFID and smartcard)
  • ADA compliant

Technical Details

Description: Electronic mortise lockset with 1" (25.4mm) throw deadbolt and 5/8" (15.9mm) dead-locking latch bolt

Handing: Factory-handed mortise (left, right, left reverse, right reverse)

Lever: ADA compliant

Deadbolt: 1" (25.4mm) throw deadbolt and 5/8" (15.9mm) dead-locking latch bolt

Door Thickness: 1 ¾" (44.5mm) to 2 ⅛" (53.98mm) for standard product

Housing Construction:

  • Escutcheons: stainless steel or brass
  • Levers: brass, zinc, or stainless steel

Standard Finishes:

  • Bright chrome
  • Bright brass
  • Satin chrome
  • Satin brass
  • Dark mahogany

Inside Trim Options: Optional ädesē or MT inside escutcheon

Standard Backset: 2 ¾" (69.9mm) from door edge to lever

Locking Options:

  • ANSI lock case with 1 ½" or 1" lock front mortise
  • Options: automatic deadbolt, door ajar, MKO
  • European lock case mortise (20 x 165 mm) with 20 x 233 mm lock front mortise

Online Configurations:

  • Messenger Ready - DAJ mortise (ANSI lock case), Standard (stand alone) inside escutcheon
  • Messenger Online - Lock controller board with Messenger capability, DAJ mortise (ANSI lock case), Inside escutcheon equipped with Messenger module

Batteries: Alkaline - Four AA battery pack

Audit Trail: Up to 4,000 events

Disability Feature: RCU readers interface with automatic power operated doors for special openings

Standard Factory Warranty: Two years
Extended Warranty: Saflok SAFGARD Service Plans (Platinum, Gold, Silver)

Certifications:

  • ADA compliant levers
  • Certified to ANSI / BHMA A156.13 mortise locks (Grade 1)
  • Certified to ANSI / BHMA A156.25 electrified locks (Grade 1)
  • Meets UL 10C and UL 10B, on fire-rated door up to and including three hours
  • Environmental Operating Conditions

    • Inside -32°F to 151°F (0°C to 66°C)
    • Outdoor side: -31°F to 151°F (-35°C to 66°C)
    • 0% to 85% non-condensing humidity at 86°F (30°C)
  • Florida Building Code (FL13061)

Functionalities

Low Maintenance

  • Batteries last up to 2 years
  • Low battery indicator alerts staff
  • Lock programming and audit records are not erased during battery replacement
  • Wear resistant construction and finish
  • Operates with a completely sealed contactless reader (RFID only)

Applications

  • Suitable for small to very large scale housing factilites
  • Easily replaces existing mechanical or electronic door locks
  • Access control for guest rooms, common areas, and back-of-the-house
  • The Saflok locks work with the Windows-based System 6000â„¢ Access Control Software, Messengerâ„¢ online wireless system and DeskLincâ„¢ front desk system.

Saflok MT RFID Satin Brass
Saflok MT RFID Satin Brass
