PowerPlex 2000 Self Powering Lock

Construction & Durability

• Heavy-duty commercial Grade 1 lockset with solid cast exterior housing and solid cast levers; cylindrical drive wear-tested for extensive indoor and outdoor use
• Vandal-resistant numeric keypad with solid metal pushbuttons

Handing

• Non-handed; pre-assembled for left-hand door installation and easily reversed in the field

Backset

• Cylindrical: 2 ¾" (70 mm) or 2 ⅜" (60 mm)
• Mortise: 2 ¾" (70 mm)
• Exit trim: varies by exit device

Latches

• Cylindrical models: ½" (13 mm) throw latch; ¾" (19 mm) throw latch optional
• Mortise models: ¾" (19 mm) latch; 1" (25 mm) deadbolt optional

Strikes

• Cylindrical models packaged with both ANSI A115.3 "T" strike and A115.2 ASA strike as standard

Minimum Stile

• 5" (127 mm)

Key Override Options

• Key-in-lever cylinder: 1539 6-pin cylinder, Schlage "C" keyway
• Interchangeable core: small format, Best and equivalent (6- or 7-pin length); cylinder not included

Installation

• No wiring to or through the door — no risk of pinched wires
• Door preparation, cylindrical and exit trim: ASA 161; installs easily on wood or metal doors with three additional through-bore holes
• Door preparation, mortise: ASA 86 with three additional through-bore holes
• Door thickness, cylindrical: 1 ⅜"–2 ½" (35–64 mm); pre-assembled to accommodate doors 1 ⅝"–2" (41–50 mm)
• Door thickness, exit trim and mortise: 1 ¾"–2 ¼" (44–57 mm); pre-assembled to accommodate doors 1 ¾"–2 ⅛" (44–54 mm)

Certifications & Testing

• Accessibility: compliant with the Americans with Disabilities Act (ADA)
• Durability: ANSI/BHMA Grade 1 certified (A156.25, A156.2, A156.13, A156.3)
• Fire rating: UL 10C fire rated
• Environment: approved for indoor and outdoor use; −31 °F (−35 °C) to +151 °F (66 °C)

Warranty

• Three-year warranty from date of installation; built-in warranty counter in lock memory

Finishes

• Standard: Satin Chrome 26D (626) housings and levers
• Optional: Satin Brass 04 (606) or Dark Bronze 744 (10B) housings and levers

Common applications include:

• Commercial offices – Executive offices, finance departments, HR, IT/server rooms, records rooms, and conference rooms
• Healthcare facilities – Staff-only areas, medication storage, laboratories, medical records, pharmacies, and administrative offices
• Educational institutions – Classrooms, faculty offices, computer labs, research facilities, equipment storage, and maintenance shops
• Industrial and manufacturing facilities – Tool cribs, maintenance rooms, production offices, quality control labs, and equipment storage
• Retail and banking – Cash offices, stockrooms, inventory storage, manager's offices, receiving areas, and employee entrances
• Hospitality – Back-of-house offices, housekeeping storage, engineering rooms, maintenance areas, and staff-only spaces
• Government and municipal buildings – Administrative offices, records rooms, evidence storage, utility rooms, and restricted work areas
• Multi-family residential – Amenity rooms, fitness centers, package rooms, maintenance offices, utility rooms, and leasing offices
• Critical infrastructure – Electrical rooms, telecom closets, pump stations, mechanical rooms, and control facilities
• Remote or hard-to-maintain locations – Doors where battery replacement is inconvenient, costly, or easily overlooked

The PowerPlex® 2000 is the ideal choice when you want to:

• Eliminate battery replacements and related maintenance.
• Avoid wiring to or through the door.
• Upgrade from mechanical keys to PIN-based access.
• Quickly add or remove users without rekeying.
• Reduce lifetime ownership costs.
• Improve sustainability with a battery-free access solution.
• Secure high-traffic openings with a reliable, self-powered lock.

The PowerPlex® 2000 is particularly well suited for facilities that prioritize low maintenance, long-term reliability, and operational efficiency. Because every lever cycle generates the energy needed to operate the lock, it delivers dependable electronic access control without batteries, making it an excellent choice for park storage facilities, commercial buildings, schools, healthcare facilities, industrial sites, and any application where maintenance resources are limited or uninterrupted operation is critical.
