Keyscan Peripheral Products

IOCB1616 input/output board

Operators rely on the IOCB1616 when system design calls for additional input and output capabilities. It provides 16 additional inputs with 16 additional open collector outputs and features DIP switch banks for easy installation, set-up and feature configuration. The board suits monitoring of exit-only doors, glass breaks, motion detectors and other sensing devices through a Keyscan system. Up to four IOCB1616 boards can be chained together for use with the CA4500 and CA8500.

• Input/output (I/O) board with 16 supervised inputs and 16 digital outputs
• For adding I/O boards to the IOCB1616 enclosure or service replacement of an existing board (maximum of 4 boards per IOCB1616 per ACU)
• Works with Rev. 10 ACUs and higher
• Smaller board format
• Inputs can monitor contacts on doors, motion sensors, push buttons or other sensing devices
• Outputs can activate CCTV cameras, burglar alarm systems, lights, HVAC, parking lot gates or other devices
• Single or multiple inputs can be assigned to trip single or multiple outputs, either open collector or optional form C relays, using any of 7 modes that include timers, delays or pulsing
• Time zones can be assigned to activate and deactivate inputs or outputs
• The access control unit communicates with the IOCB1616 boards via RS485 over twisted pair cable

OCB8 relay output board

The OCB8 is a form C relay output board designed as a dry contact closure for Keyscan door and elevator floor controllers and auxiliary equipment. It provides auxiliary service expansion such as additional doors or elevator floor stops, and can trigger secondary responses such as sirens, alarms or strobe lights, or increase access restriction parameters, with the Keyscan EC1500, EC2500, CA4500 or CA8500 controllers. The OCB8 is time programmable and features a DIP switch bank for easy changes to relay states.

• DIP switch plug on board with independent reverse pole switches for relay control
• Works with all current and previous ACUs/ECUs
• Adds auxiliary outputs to Keyscan CA4500 and CA8500 door controllers to trigger responses such as sirens, alarms and strobe lights, or to further restrict access
• Time programmable (via software)

WIEEX2 Wiegand extender

The WIEEX2 expands the distance between access control panels and readers that support the Wiegand data format, with a cable distance of up to 4,000 ft (1,219 m) for hard-to-reach locations. Built-in door status monitoring, an unlock relay and request to exit (REX) inputs also reduce installation costs. The WIEEX2 works with any Wiegand-compatible access control unit by converting the Wiegand signal to standard RS485 communications between the transmitter and receiver.

• Converts the Wiegand signal to standard RS485
• Communication range of up to 4,000 ft (1,219 m) between the WIEEX2 receiver and WIEEX2 transmitter, using standard CAT5 cable between access control units

DPS-15 power supply

The DPS-15 is a dual linear DC power supply designed for an access control unit panel, readers and auxiliary outputs. It operates from two 16 VAC 40 VA transformers and supplies two 12 VDC, 1.2 A outputs. The DPS-15 is included with the Keyscan door and elevator floor controllers (CA250, CA4500, CA8500, EC1500 and EC2500).

• Supplies up to 1.2 A for each of two segments
• Included with each Keyscan CA Series door controller and EC Series elevator floor controller

CIM (Communication Interlink Module)

• The CIM is a communication control module that uses a CAN Bus communication network. It provides optimized server-to-access control unit (ACU) communication and creates an inter-panel ACU-to-ACU network for global functions including anti-passback, global input/output and global time zones. The CIM adds ground loop protection, enhanced diagnostics and improved speed.
• Provides optimized server-to-ACU communication
• Gives users an ACU-to-ACU network for inter-panel communication and global functions
• Standardized cabling: communication links use the CAN Bus protocol over standard CAT5 cabling
• Ground loop tolerance: maximizes electrical isolation to earth ground
• Fault tolerance: if one CIM fails it does not take the loop down; the CAN Bus protocol keeps the remaining devices on the network communicating
• Optimized communication speeds, up to 115 kbps
• Enhanced diagnostics for quick troubleshooting
• Auto bit rate configuration automatically matches the bit rate to the control unit configuration
• Supports the Keyscan plug-on TCP/IP network adapter NETCOM2P/6P
• Simplified ribbon cable connection to the control unit for fast installation
• Access control units connected directly to the CAN Bus network communicate ACU to ACU without server dependence, enabling additional features and capabilities

CIM-Link

The CIM-Link is a TCP/IP companion module that brings multiple CIM CAN Bus communication loops into a single global infrastructure. It extends CAN Bus based ACU communications over a common LAN/WAN network, expanding ACU-to-ACU functionality to multiple independent CAN Bus global networks for maximum system design flexibility.

• Maximizes system design options
• Greater global communication flexibility
• Expands ACU-to-ACU functionality to multiple independent CAN Bus global networks
• Ground loop tolerance: maximizes electrical isolation to earth ground
• Enhanced diagnostics: communication diagnostics shown on on-board light-emitting diodes (LEDs) for quick device-based troubleshooting
• Uses the Keyscan plug-on TCP/IP network adapter NETCOM2P/6P
• TCP/IP tunneling ensures uninterrupted, reconnecting communication between CIM-Links
• Supports global functions between groups of multiple ACU panels, or a single ACU panel, over an existing LAN/WAN network
• Delivers global communication over the CAN Bus network; ACUs connected directly to the CAN Bus communicate ACU to ACU without server dependence
• Simplified ribbon cable for fast installation
• Fault tolerance: if one CIM-Link goes down it does not take the loop down; the CAN Bus protocol keeps the remaining devices communicating

NETCOM2 off-board TCP/IP module

The NETCOM2 is an off-board TCP/IP communication module that establishes access control units as network-appliance based units. It functions with current and legacy access control units and allows a quick connection to an existing LAN/WAN network infrastructure. DIP switches provide convenient set-up, and the module is programmable for configuration on a network.

• Embedded IP addresses for programming the device on a local network
• Serial connection from the ACUs via a 10/100 RJ45 network interface to communicate with a server or PC host
• Static TCP/IP addresses allow communication over an existing LAN/WAN network
• Unlimited units can be added to a system, supporting enterprise deployments
• Fast, trouble-free off-board installation
• Allows one or more access control units to communicate on a LAN/WAN
• DIP switch settings for convenient configuration
• Fast and easy installation for each ACU
• Static TCP/IP communication protocol between the PC network interface card (NIC) and access control units fitted with NETCOM2
• Requires static IP addresses for proper operation
• Simplifies installation and maintenance procedures

NETCOM2P plug-on TCP/IP adapter

The NETCOM2P is a plug-on TCP/IP communication adapter module that connects directly to Keyscan networked access control systems. The Keyscan NETCOM adapters are a fast and easy way to connect a Keyscan access control system to a LAN/WAN network: they plug onto the CIM for network communication, or directly onto the control board for single access control unit applications.

• Where higher security is required for communication, use the NETCOM6P with the AES Rijndael (NIST approved) encryption algorithm
• A user-defined encryption key of 128, 192 or 256 bits minimizes the possibility of a communication breach
• Includes the Keyscan NETCOM Program Tool utility for custom installation programming
• Also available as an off-board module, NETCOM2, for legacy panels and select integrations
• Fast and easy installation for each ACU
• Requires static IP addresses for proper operation
• Simplifies installation and maintenance procedures
• Easy to program with the included utility
