Power Supplies: Field selectable voltages that filter & regulate DC output

RCI WPDT Wireless Power & Data Transfer

An innovative and less intrusive way of wirelessly transferring low voltage power and data signals between a door and frame.

  • Output voltage – 12VDC/24VDC field selectable
  • Output amperage - 600mA/12VDC ,300mA/24VDC
  • Maximum input power – 600mA @ 24VDC
Downloads

Product details

  • Ideal for situations where power cannot be routed to an electric lock in the door.
  • Enables less wire runs to various points of the door.
  • Eliminates a power transfer hinge or other method of power transfer.
  • Two-piece device has an RF receiver and transmitter – transmitter resides on the frame side while the receiver resides in the door.
  • For fail secure devices only.
  • Power is delivered to the transmitter that transfers power/data wirelessly to the receiver.
  • Ability to monitor RX, LBM, DBM (max 2 signals)
  • Status indicators (frame & door side).
  • Monitoring function(s) report change of state of the lock switches back to a control panel.

  • UL 10C, Classified as a miscellaneous fire door accessory
  • FCC and ISED compliant
  • Patent: US 9,235,942 B2
