RT Plus

dormakaba’s RT Plus is an enhanced version of the proven RT RFID electronic lock, offering the BLE technology directly integrated in the reader. Ideal for retrofit, this durable lock is easy to use and works with Ambiance and System 6000, access management softwares.

RT Plus is an easy path to RFID for properties wishing to upgrade: The switch is as simple as replacing the outside housing while keeping the same door preparation.

Mobile Access:

The lock is mobile access capable with the dormakaba BLE module integrated in the reader.

NFC Programming
Mobile access enabled lock
Retrofit, new doors and new construction application
Works with Ambiance and System 6000 access management softwares
Remote lock management with Ambiance RX

Product Details

Security Features
High security and tamperproof design
1” solid deadbolt (optional auto deadbolt)
Staff monitoring (Keycard Audits)
Emergency access: Emergency keycard, mechanical key and electronic override

Technical Details

ADA Standard levers: bright chrome, bright brass, satin chrome, satin brass, dark mahogany

Door Thickness: 13/4" (44.5mm) to 21/8" (53.98mm) for standard product

Locking Options:

ANSI lock case with 11/4 or 1” lock front mortise
Options: automatic deadbolt, door ajar, MKO
European lock case mortise (20 x 165 mm) with 20 x 233 mm lock front mortise
RFID credentials: MIFARE Ultralight C and MIFARE Plus* available
_{*MIFARE Plus EV2: Should be used in conjunction with enhanced security mode available in Ambiance v2.10}

BHMA and UL certified

dormakaba products are certified to a number of performance-oriented standards. In obtaining these certifications, dormakaba ensures product durability and performance, give our customers the peace of mind that comes with owning a quality solution that meets and exceeds industry standards for access control, life safety, and security.

Functionalities

Low Maintenance
Batteries last up to 2 years
Low battery indicator alerts staff
Lock programming and audit records are not erased during battery replacement
Operates with a completely sealed contactless reader
Wear resistant construction and finish
NFC Programming

Components

The following dormakaba components are needed for a full functionality of the RT Plus lock:

Core Package:

Ambiance Access Management software
dormakaba RFID encoder
dormakaba Maintenance Unit
Keycards and/or credentials

Optional:

Ambiance RX for remote lock management
Ambiance MX, for mobile access
Ambiance PX, for enhanced perimeter access
A dormakaba Mobile Access Solution Program

Applications

Ideal for retrofit projects
Easy and simple upgrade from magstripe locks by only replacing the outside housing
Same door preparation for ease of installation
Suitable for small to very large-scale properties
Access control for guest rooms, common areas and back-of-house
