Product Summary

Elevate your architectural design with the CDS Door Rails, meticulously crafted to provide robust solutions for heavy-duty and wide doors. Designed to integrate seamlessly with dormakaba’s hardware solutions, this system offers superior performance and aesthetic appeal, ensuring your building projects achieve the highest standards of quality and security.

  • Enhanced door support for heavy-duty or wide doors
  • Improved security options with 950 style deadlocks
  • Rail cover removal is quick and easy
  • Simplified installation and adjustment without removing glass

Product Details

CDS Door Rails are the epitome of strength and elegance, tailored for diverse architectural needs. Ideal for heavy-duty applications, these fittings support glass thicknesses from 10mm to 19mm, accommodating door weights of up to 150kg. The CDS design facilitates quick rail cover removal and easy door adjustment, ensuring a seamless installation process.

Engineered for precision, these fittings require no glass preparation, eliminating the need for drilling or cutouts. This feature preserves the integrity of the glass while offering a firm and secure attachment. With a choice of finishes, including Satin Stainless Steel, Polished Stainless Steel, Satin Anodised Aluminium, and Powder coated options, you can customise your fittings to match the aesthetic of any space.

Technical Details

  • Designed for tempered safety glass (TSG) and laminated safety glass (LSG).
  • Suitable for glass thickness ranging from 10 - 19mm. Available in SSS, SAA, PSS & special finish.
  • Supports a maximum weight of 150kg per panel.
  • Lock operation either with cylinder or turn.
  • Available in throw lock or pin lock.
  • Base material is extruded aluminium.
  • Application with one or two panels, single or double action, & fixed side lights.
  • For pivoting and sliding doors.

Components

  • Rail cover
  • Base fitting extrusion
  • Accessories

Applications

  • Shop front access
  • Shop front display
  • Commercial building
  • Industrial building
  • Meeting rooms or offices

052166_1200x1200.jpg_image_slider_product_image_slider_zoom_v2
CDS Door Rails_2
CDS Door Rails_3
