RCI 8365 Mortise MicroMag

The compact 8365 Mortise MicroMag® is designed for securing small enclosures, cabinets, and sliding doors. This special low-profile lock has up to a 300lbf holding force. The RCI 8365 Mortise MicroMag® is a low energy consumption lock and is field-selectable at 12/24 VDC.

8365 Mortise MicroMag Electromagnetic Locks RCI EAD
  • Energy: 400mA Field-Selectable 12/24VDC (Max at 12VDC)
  • Strength: Up to 300lbf Holding Force
  • Warranty: Lifetime Limited Warranty
  • Mode: Fail-Safe

Product Details

  • Low-profile design ideal for sliding doors, cabinets and small enclosures
  • 400mA Field-Selectable 12/24VDC (Max at 12VDC)
  • Up to 300lbf Holding Force
  • Lifetime Limited Warranty
  • Fail-Safe

Technical Details

Dimensions: 7-15/16"W x 1-11/32"H x 13/16"D (202mm x 34mm x 21mm) – Includes 11/16" (17.5mm) mounting tabs
Armature Plate: 5-1/8"W x 1-1/4"H x 21/64"D (130mm x 32mm x 8.5mm)

  • Brushed Anodized Aluminum (28) finish

Components

Armature Plates

  • AP04 5/16" (8mm) Steel

Applications

  • Perimeter and interior sliding doors
  • Small enclosures
  • Cash drawers
  • Vending machines
  • Filing cabinets
  • Industrial
  • Commercial
  • Residential
  • Health Care
  • Retail
