SL30SGL - Electronic Side Load Lock

The SL30SGL electronic side load lock is a motor driven electronic lock designed to secure commercial and residential single action doors. The SL30SGL has a compact footprint that makes installation flexible, without compromising it’s capability to realign the door against a seal. It can also release instantly when requested, even with excessive load on the door.

High security for single action doors
10,000N holding force (1,000kg)
Door misalignment of up to 8mm is corrected
Sideload up to 600kg
Economical solution – less than 40Ma standby current

Product Details

Door misalignment of up to 8mm is corrected
Side load release – The door can have in excess of 600kg being applied and it will still release instantly when requested.
Automatic deadbolting
10mm thick stainless steel bolt pin
10,000N holding force (1,000kg)
Reverse polarity and transient protection
Multiple attempts to lock
Input voltage from 12VDC -24VDC
Convert from Fail Safe to Fail Secure by repositioning a single jumper
Door and bolt position monitors
Mortice mount horizontally or vertically, on single acting doors
Surface mount with the aid of the SLA30SGL accessories, including mounting onto glass
