Skyfold Zenith® Series

This Series consist of Zenith 48,Zenith 51,Zenith 55, Zenith 60, 0.65NRC. Zenith combines the vertically folding elements found in the Classic series at the top portion of the wall with a slick straight down descent thereafter, which makes it the ideal flexible space solution for areas that may have wall obstructions which could limit the use of a vertically folding partition wall. With the Zenith’s narrow path of travel, you don’t have to overhaul the placement of the furniture in the space to operate the partition wall.

Easy-to-Use Turn-Key or Digital Keypad Operation
Retracts into the Ceiling to Maximize Floor Space
Industry-Leading STC ratings
Narrow path of travel allowing furniture to be positioned in very close proximity to the wall
No Floor, Wall Tracks or Visible Hinges
Fully Automatic
Quiet Operation
Light weight resulting in savings in structural steel
Flat and Rigid
Cost-Effective and Lightweight Structure
Can be Installed to meet at 90° intersections
Can be used in Stepped and Sloped Floors
Equipped with a Safety Obstruction Sensor
Variety of Finish Options
Made to Last
Not expensive to replace damaged panels

Product Details

Zenith 48 provides an economical model for low budget projects , but still achieving all the features of other Zenith models with regards to the folding mechanism.

Technical Details

Acoustic Rating of System – Starting from 48 STC(47RW) up to STC 60 (RW 59) , also available Classic NRC with STC 50 (RW 49) NRC up to 0.65
Acoustic Rating of Panels – up to STC 66 (RW 64)
Max. Wall Height -3660mm
Max. Wall Length –14600mm for Zenith 48 and unlimited length for other models
Weighs 29.4 to 42.1 kg/m2, compared to 48.8 to 58.6kg with conventional walls
Ceiling Space Required for Storage (approx.*) – Varies from 615mm to 820mm
Ceiling Pocket Width (approx.*) – Varies from 1400mm to 1615mm
Finish Options- Zenith 48 is available in our standard vinyl, fabric, paint or white marker board surface finishes only. Zenith 51, Zenith 55 and Zenith 60 are available in vinyl, fabric, specialty metals, plastic lami-nates, marking surfaces, wood veneer, and more with all finishes can be mixed and matched. Zenith NRC is available in acoustically transparent fabric only.
No Floor & Wall Tracks
Back-Up Operation
Obstruction Safety Sensor with auto reverse function
Warranty – for Parts & Labor up to 2 Year or 5000 cycles which occurs first. Optional Extended Warranty available upon request.
Digital Touch Screen Option Available

Functionalities

Skyfold Zenith walls combines the vertically folding elements found in the Classic series at the top portion of the wall with a slick straight down descent thereafter. Operated using push button or using touch screen
